Figures

Paper figures are stored in the repository under img/. The site references GitHub raw URLs instead of duplicating binary images under docs-site/.

Suggested Use

figure 002 000

figure 002 001

figure 006 008

Full Embedded Figure List

Figure What it shows Best page
002-000 mmWave radar board. Radar Basics
002-001 Radar imaging or target-outline result. mmLock Paper
002-002 Radar heatmap / energy map. FFT Pipeline
002-003 3D radar point cloud. Point Cloud
002-004 Human-shaped point cloud. Point Cloud, CNN + BiLSTM
004-005 Color scale for a heatmap or point-cloud plot. Use with paired figure
005-006 Radar heatmap. ADC to Radar Cube
005-007 Color scale for a radar plot. Use with paired figure
006-008 Multi-target or clustered point cloud. Security Scenario
006-009 Experiment capture setup. Project Notes
006-010 Close-up of radar and development board. Project Notes
007-011 Loss and validation-loss curve. Training Flow
007-012 Accuracy and validation-accuracy curve. Training Flow
007-013 Another loss curve, likely for another training stage. Training Flow
007-014 Another accuracy curve paired with the previous loss curve. Training Flow
008-015 Radar board view. mmLock Paper
008-016 Radar sensing output paired with hardware. FMCW Radar
008-017 Wireless/radar wave icon. Wireless Sensing
008-018 Radar board view. Experiment setup
008-019 Radar sensing output. Experiment setup
008-020 Wireless/radar wave icon. Radar Basics
009-021 Radar board view. Experiment setup
009-022 Radar sensing output. Experiment setup
009-023 Wireless/radar wave icon. FMCW Radar
